AV Signal Distribution
Aten Splitter, HDMI, 2 Port – VS182A
R1,489.62
• Connects one HDMI source to two HDMI displays at the same time
• HDMI (3D, Deep Colour, 4kx2k); HDCP 1.4 Compliant
• Long distance transmission – up to 15 m (24 AWG)
• Supports max. data rate of 10.2 Gbps
- Brand :Aten
- SKU :ATEN-VS182A
- Category :AV Signal Distribution
- Availability :
In Stock
13 in stock
Description
The VS182A HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to two displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes and all HDMI displays.
The VS182A HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theatre applications, as well as in corporate, educational and commercial settings.
Package Contents
- 1x VS182A 2-Port HDMI Splitter
- 1x Power Adapter
- 1x HDMI Cable
- 1x User Instructions
Video Input
| Interfaces | 1 x HDMI Type A Female (Black) |
|---|---|
| Impedance | 100 Ω |
| Max. Distance | 3m @3840x2160@30 (4:4:4) |
Video Output
| Interfaces | 2 x HDMI Type A Female (Black) |
|---|---|
| Impedance | 100 Ω |
| Max. Distance | 15m @3840x2160@30 (4:4:4) |
Video
| Max. Data Rate | 10.2 Gbps (3.4 Gbps Per Lane) |
|---|---|
| Max. Pixel Clock | 340 MHz |
| Compliance | HDMI (3D, Deep Colour, 4K); HDCP Compatible |
| Max. Resolution | Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
Audio
| Input | 1 x HDMI Type A Female (Black) |
|---|---|
| Output | 2 x HDMI Type A Female (Black) |
Connectors
| Power | 1 x DC Jack |
|---|
Environmental
| Operating Temperature | 0-50 °C |
|---|---|
| Storage Temperature | 20 - 60 °C |
| Humidity | 0 - 80% RH, Non-Condensing |
Physical Properties
| Housing | Metal |
|---|---|
| Weight | 0.31 kg ( 0.68 lb ) |
| Dimensions (L x W x H) | 12.50 x 8.00 x 2.50 cm (4.92 x 3.15 x 0.98 in.) |
| Carton Lot | 20 pcs |
| Power Consumption | DC5.3V:3.12W:15BTU |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
You must be logged in to post a review.
VS182A Datasheet PDF
